Signal-Stat, LED, Yellow Round, 24 Diode, Single Face, 3 Wire, Pedestal Light, 1 Stud, Chrome, Stripped End/Ring Terminal
Common Root | 2751A |
---|---|
Common Size | 4.5" |
Country of Origin | TW |
Current Minor | 0.03 |
Features & Benefits | Chrome plated housing|Ideal for show trucks, highway mowing, municipal and farm equipment |
Housing Color | Chrome |
Housing Material | Zinc |
Itm Id | 2847686 |
KIT (Yes/No) | No |
Lens Shape | Round |
Lighting Technology | LED |
Lamp Connection | Hardwired |
Lens Color | Yellow |
Lens Height_INH | 4.5 |
Lens Material | Polycarbonate |
Lens Width_INH | 4.5 |
Mounting Orientation | Universal |
Mount Type | 1 Stud Mount |
NAPA Part Number | 2751A |
Number of Diodes/Bulbs | 24 |
Number of Wires | 3 |
Packaging Type | Standard |
Part Number | SS2751A-S |
Plug Side One | Hardwired |
Plug Side Two | Stripped End|Ring Terminal |
Position | Universal |
Sealed/Bulb Replaceable | Sealed |
Side Marker (Yes/No) | No |
Standards Met | I6 |
Std Carton Qty | 1 |
Taxonomy | Lights.Pedestal Lights |
Total Depth_MMT | 43.18 |
Total Depth | 1.7 |
Temp. Description | SIGNAL-STAT LED SF PED LAMP A |
Total Height_MMT | 114.3 |
Total Height | 4.5 |
Total Length | 0.36 |
Total Width_MMT | 114.3 |
Total Width | 4.5 |
UNSPSC/Tariff | 25172900 |
UPC | 735111151449 |
VMRS | 034-003-141 |
Voltage (VLT) | 12 |
Weight | 1.01 |
